Cyclic Code

Introduction

Example: Consider the binary code $C=\{000, 110, 011, 101\}$. Firstly, this is a linear code for the sum of any two codewords in $C$ is also in $C$. We can denote a codeword in $C$ by $c=(c_1, c_2, c_3)$ where $c_i$ is either 0 or 1. Then the significant property of cyclic code is tthat if $(c_1, c_2, c_3)\in C$, we have $(c_3, c_1, c_2)$ is again a codeword in $C$. And this is why code method called Cyclic Code.

Definition (Cyclic Code) A binary code is cyclic if it is a linear [n, k] code and if for every codeword $(c_1, c_2, \dots, c_n)\in C$ we also have that $(c_n, c_1, \dots, c_{n-1})$ is again a codeword in $C$.

Polynomials over $\mathbb{F}_2$

Using polynomials to invast cyclic code would make things easy. We use $\mathbb{F}_2\{x\}$ to denote the set of all polynomials

\[a_0+a_1x+\dots+a_mx^m\]

with $a_i\in\mathbb{F}_2$.

Definition (Code Polynomial associated to a Cyclic Codeword) For each $a=(a_0, a_1, \dots, a_{n-1})$, $a$ is a codeword in a cyclic [n, k] code $C$. Define the polynomial associated to $a\in C$ to be \(a(x):=a_0+a_1x+\dots+a_{n-1}x^{n-1}\in\mathbb{F}_2[x]\)

Notice that the right cyclic shift (the shift in introduction) of $a(x)$ is $a_{n-1}+a_0x+a_1x^2+\dots+a{n-2}x^2{n-1}$. Compare these two polynomials, it is clear that $xa(x)=a_{n-1}(x^n-1)+a_{n-1}+a_0x+\dots+a_{n-2}x^{n-1}$. In other words,

\[\begin{equation} xa(x)\equiv a_{n-1}+a_0x+a_1x^2+\dots+a_{n-2}x^{n-1}\pmod{x^n-1}\label{eq:mod}\tag{1} \end{equation}.\]

Constructing Cyclic Codes

First, consider the polynomial operations over the $\mathbb{F}_2$. Just like number operation over $\mathbb{F}_2$, we need take the modulus 2 to the coefficients after normal operation.

For example:

\[\begin{align} (x^3+x)+(x+1)=&x^3+2x+1=x^3+1\\ (x^2+x)(x+1)=&x^3+2x^2+x+1=x^3+x+1\\ \frac{x^3+x^2+x}{x+1}=&x^2+1\dots -1=x^2+1\dots 1. \end{align}\]

Now, we can begin to constructe the cyclic code.

Assume a fixed $g(x)\in\mathbb{F}_2$ divide the polynomial $x^n-1$, and the degree of $g(x)$ is $n-k$ for some $0\leq k\leq n$. And a variable polynomial $\alpha$ with $deg(\alpha(x))<k$. Use $f(x)$ denote the $g(x)\cdot\alpha(x)\bmod{x^n-1}$. Each $f(x)$ can be written as

\[f(x)=a_0+a_1x+\dots+a_{n-1}x^{n-1}.\]

Recall the follow equation

\[\begin{align} x\cdot f(x)=&a_0x+a_1x^2+\dots+a_{n-2}x^{n-2}+a_{n-1}x^{n-1}\\ =&a_{n-1}(x^n-1)+a_{n-1}+a_0x+\dots+a_{n-2}x^{n-1}\\ =&a_{n-1}(x^n-1)+h(x). \end{align}\]

We know that $f(x)$ is divisible by $g(x)$ and $g(x)$ divide $x^n-1$, thus both $x\cdot f(x)$ and $a_{n-1}(x^n-1)$ are divisible by $g(x)$. Hence $h(x)$, the right cyclic shift of $f(x)$, is divisible by $g(x)$. Therefore we get follow theorem.

Theorem (1): Fix an integer $n>1$. Let $g(x)\in\mathbb{F}_2$ divide the polynomial $x^n-1$. Assume the degree of $g(x)$ is $n-k$ for some $0\leq k\leq n$. Consider the set of polynomials

\[\mathcal{P_g}:=\{g(x)\cdot\alpha(x)\pmod{x^n-1}\mid\alpha(x)\in \mathbb{F}_2\ with\ deg(\alpha(x))<k\}.\]

Every code polynomial $f(x)\in\mathcal{P_g}$ can be written in the form

\[f(x)=a_0+a_1x+\dots+a_{n-1}x^{n-1}.\]

Then the set of all ${a_0, a_1, \dots, a_n}$ coming from $f(x)\in\mathcal{P_g}$ form a cyclic $[n, k]$ code.

So, we have proved that $g(x)$ could construct cyclic code, so it is called generator polynomial, and next is to prove all cyclic codes are constructed by $g(x)$.

First, for every cyclic code $C$, the $g(x)$ with minimal degree is unique.

Assume distinct polynomials $g_1(x)\in\mathbb{F}_2$ and $g_2(x)\in\mathbb{F}_2$ are the minimal degree generator polynomial in cyclic code $C$. Then $g_1(x)-g_2(x)$ would have a smaller degree than $g_1(x)$ or $g_2(x)$ since the coefficient of highest order of $g_1(x)$ and $g_2(x)$ must be $1$. Recall the properties of cyclic code, $\alpha(x)g_1(x)-\alpha(x)g_2(x)$ are also in $C$. Therefore, $g_1(x)-g_2(x)$ is the generator polynomial of $C$. This is a contradiction so the polynomial $g(x)$ of minimal degree must be unique.

Secondly, if a cyclic code $C$ can be constructed by $g(x)$ via Theorem(1), $g(x)$ divides $x^n-1$.

Assume $g(x)$ does not divide $x^n-1$. Thus

\[x^n-1=g(x)\beta(x)+r(x),\qquad (\beta(x), r(x) \in \mathbb{F}_2[x])\]

And $r(x)$ is remainder polynomial which must have smaller degree than $g(x)$. Thus:

\[\begin{align} r(x)\equiv&-g(x)\beta(x)\pmod{x^n-1}\\ \equiv&g(x)\beta(x)\pmod{x^n-1}\\ \end{align}.\]

In this case, $r(x)$ is a codeword in $C$, and must higher degree than $g(x)$, which is a constradiction.

In conclusion, we have theorem 2:

Theorem (2): Let $C$ be a cyclic code. Then there exists a uniquely determined code polynomail $g(x)$ of minimal degree in $C$ which has the following properties.

1. $g(x)$ is unique;
2. $g(x)$ divides $x^n-1$;
3. The code $C$ can be constructed using $g(x)$ as in Theorem (1).

The polynomial $g(x)$ is called the generator polynomial for the code $C$.

The polynomial $h(x)$ which determined by

\[g(x)h(x) = x^n-1\]

is the check polynomial for the code $C$.

Example

If fix $n=7$, we have $x^7-1=(x-1)(x^3+x+1)(x^3+x^2+1)$. Since we are in the binary finite field, rewrite the factorization as $1+x^7=(1+x)(1+x+x^3)(1+x^2+x^3)$.

• $g(x)=1, \qquad C=\mathbb{F}^7_2=[7, 7]\ code$
• $g(x)=1+x, \qquad C=[7, 6]\ code$
• $g(x)=1+x+x^3, \qquad C=[7, 4]\ code$
• $g(x)=1+x^2+x^3, \qquad C=[7, 4]\ code$
• $g(x)=(1+x)(1+x+x^3), \qquad C=[7, 3]\ code$
• $g(x)=(1+x)(1+x^2+x^3), \qquad C=[7, 3]\ code$
• $g(x)=(1+x+x^3)(1+x^2+x^3), \qquad C=[7, 1]\ code$
• $g(x)=1+x^7, \qquad C={0000000}=[7, 0]\ code$

Check

Theorem (3): If $h(x)$ is the check polynomial of cyclic code $C$, then

\[C(x) = \left\{ c(x)\in\mathbb{F}_2\{x\}\mid c(x)h(x)\equiv 0\pmod{x^n-1} \right\}\]

PROVE: As metioned-above, $c(x)=g(x)\alpha(x)$. Hence

\[\begin{aligned} c(x)h(x)\equiv & g(x)\alpha(x)h(x) \pmod{x^n-1}\\ \equiv & (x^n-1)\alpha(x) \pmod{x^n-1}\\ \equiv & 0 \pmod{x^n1} \end{aligned}\]
